Microservices Architecture — Docker Compose Setup!
Welcome to the documentation for the microservices architecture development environment! This repository includes a docker-compose.yml file designed to spin up all necessary services for local development.
🚀 Overview
This Docker Compose setup orchestrates multiple services that together form a microservices-based application ecosystem. It is only intended for development purposes and includes:
- NATS & NATS UI: Messaging system with JetStream enabled for event streaming and an admin UI for monitoring.
- MongoDB: Document-oriented NoSQL database for data storage.
- MinIO: High-performance, S3-compatible object storage.
- Various Application Services:
- Gateway: API gateway routing requests.
- User Service: Manages user data and authentication.
- Angebot Service: Business-specific service for offers management.
- Media Service: Handles media file uploads and processing.
- Frontend & NGINX: Web frontend served through NGINX with HTTPS support.
📦 Services Included
| Service | Description | Ports |
|---|---|---|
| nats | Messaging server with JetStream enabled | 4222, 8222 |
| nats-ui | NATS monitoring UI | 31311 |
| mongo | MongoDB database | 27017 |
| minio | Object storage (S3 compatible) | 9000 (API), 9001 (Console) |
| gateway | API Gateway | 8081 |
| user-service | User management | 8082 |
| angebot-service | Offers management | 8084 |
| media-service | Media handling | 8083 |
| frontend | Web frontend | 8080 |
| nginx | Reverse proxy & HTTPS termination | 80, 443 |
⚙️ How to Run
Make sure you have Docker and Docker Compose installed.
Clone the repository:
git clone https://github.com/Konzepte-moderner-Softwareentwicklung/Backend.git cd Backend
